Name: Ubiquiti UniFi Device Bridge Pro 5GHz Wireless Bridge with PoE Out
Brand: Ubiquiti
SKU: UDB-PRO
Price: 4895.00 ZAR
Availability: InStock

Ubiquiti UniFi Device Bridge Pro 5GHz Wireless Bridge with PoE Out

0 /5.0 (0 reviews)

SKU UDB-PRO

A 5 GHz outdoor wireless bridge for linking two buildings or a gate camera without trenching cable. It reaches 5 km and more between two units, or it can uplink to a nearby UniFi access point. A PoE output port lets it power a camera or AP at the far end.

Key features

5 GHz bridge with 5 km plus range
19 dBi integrated antenna, 867 Mbps max data rate
Two GbE ports, one with PoE output
IPX6 weatherproof, pole mount included
PoE adapter included

Specifications

Dimensions	⌀189.5 x 64.3 mm; (⌀7.4 x 2.5")
WiFi Standard	WiFi 5
Spatial Streams	2
Coverage Area	5 km (3.1 mi)
Mounting Locations	Wall, pole
Mounting	Pole (Included)
Weatherproofing	IPX6
Power Method	PoE; PoE+ (Required for PoE output)
Power Supply	48V, 0.32A PoE adapter (Included)
MIMO (5 GHz)	2 x 2
Max. Data Rate (5 GHz)	867 Mbps (BW80)
Antenna Gain (5 GHz)	19 dBi
Max. TX Power (5 GHz)	25 dBm
Max. Conducted TX Power	25 dBm (Combined)
Wireless Security	WPA2 AES
Max. Power Consumption	9W
Networking Interface	(2) GbE RJ45 ports
Antennas	Internal
