Name: Ubiquiti UniFi 5G Backup RedCap Modem with PoE and eSIM
Brand: Ubiquiti
SKU: U5G
Price: 2475.00 ZAR
Availability: InStock

Ubiquiti UniFi 5G Backup RedCap Modem with PoE and eSIM

0 /5.0 (0 reviews)

SKU U5G

A small 5G RedCap modem that plugs into your UniFi gateway and takes over automatically when your fibre or main line drops. It powers from a single PoE cable and takes a nano-SIM or eSIM. This is the EU version, with the LTE bands South African networks use (B1, B3, B8, B20, B28, B38, B40).

Key features

Automatic internet failover for UniFi consoles and Cloud Gateways
5G RedCap with LTE fallback
Peak 5G SA speed of 220 Mbps down and 120 Mbps up
Nano-SIM slot plus eSIM
Powered by 802.3af PoE, one cable for data and power
Desk stand, wall and window mounts included

Specifications

Dimensions	Device: 200 x 38 x 20.2 mm; (7.9 x 1.5 x 0.8"); Table stand: 48.1 x 48 x 55.2 mm; (1.9 x 1.9 x 2.2")
Networking Interface	(1) GbE RJ45 port; 5G RedCap and LTE
SIM	(1) Nano SIM (4FF); (1) eSIM
PoE Interface	(1) PoE input
Mounting	Desktop stand, wall, window mount (Included)
Weight	Device: 122 g (4.3 oz); Stand: 138 g (4.9 oz); Wall mount: 66 g ( 2.3 oz)
Enclosure Material	Polycarbonate, aluminum alloy
5G NR (Category)	5G RedCap
5G NR (Frequency Bands)	n1, n3, n5, n7, n8, n20, n26, n28, n40, n41, n77, n78
5G NR (Max. TX Power)	23 dBm
4G LTE (Frequency Bands)	B1, B3, B5, B7, B8, B18, B19, B20, B26, B28, B38, B40, B41, B42, B43
4G LTE (Max. TX Power)	HPUE power class 2: 26 dBm
Peak Data Speed (5G SA)	Downlink 220 Mbps / Uplink 120 Mbps
Peak Data Speed (4G LTE)	Downlink 195 Mbps / Uplink 100 Mbps
Antennas (Type)	(2) Embedded omni-directional cellular antennas
Power Method	PoE (IEEE 802.3af)
Display	1.14" status display
Ambient Operating Temperature	0 to 40 °C (32 to 104 °F)
